PVC-U male union M59
Size: 20x1/2"~63x2"
Process: Injection
Origin: P.R. of China
Color: blue, green, white
MOQ: 10 cartons
Packing: export standard cartons
Logo: CXM or OEM or without brand
Prices: FOB, CNF, CIF, EX-WORK
Delivery time: within 30-45 days
Production capacity: 1000000pcs per month
| Quantity: | |
|---|---|
-
M59
-
CXM or OEM or without brand
PVC-U male union with BS thread
***INTRODUCTION
As the series of piping network products for water supply and drainage with mature technology. Pipes and fittings of PVC-U are one of the largest outputs for plastic products in the world, which already had been used widely both at home and abroad. For PVC-U water supply piping network, the row materials and finished products are both match or exceed the relative standards. So PVC-U piping network can suit for the equipments of drinking water supply. The piping networks are designed for the uninterrupted supply of water condition from 20℃ to 50℃. Under this condition, service life of piping network can up to 50 years. PVC-Y piping network have the full series size and model of fittings for building water supply, which can suit for many kinds of requirement.
This series of fittings can match the BS threaded standard - BS EN 10026-2 and BS 21.
***FEATURES OF PVC-U MALE UNION WITH BS THREAD:
1. High flow ability
The inside and outside wall are smooth, the coefficiend of friction is small, roughness is only 0.008 to 0.009, anti-fouling property is strong, fluid transport efficiency is enhanced 25% than cast iron piping network.
2. Corrosion resistant
PVC-U material has strong resistance to most of acid and alkali. No rust, no antisepic treatment. The service life is 4 times than that of cast iron.
3. Light weight and easy installation
Weight is very light. The density of PVC-U is only 1/5 to 1/6 of that of cast iron. The method of connection is very simples, and the process of installation is very quickly.
4. High tensile strength
PVC-U has high tensile strength, and high shock strength. The piping network of PVC-U is not wady to break, and it works safety.
5. Long service life
The piping network with normal material can be used around 20 to 30 years, the the PVC-U piping network can be used longer than 50 years.
6. Cheaper price
The prices of PVC-U piping network are cheaper than that of cast iron.
***FIELDS OF APPLICATION:
Piping networks for water supply in building.
Piping networks for piping system in water treatment plant.
Piping network for water farming.
Piping network for irrigation, normal water transport for industry.
***SPECIFICATION OF PVC-U MALE UNION WITH BS THREAD:
| Size (inch) | Z (mm) | L (mm) | D (mm) | M (inch) |
| 20x1/2" | 21 | 60 | 64 | 1/2" |
| 25x3/4" | 21 | 62 | 70 | 3/4" |
| 32x1" | 21 | 64 | 80 | 1" |
| 40x1-1/4" | 26 | 68 | 86 | 1-1/4" |
| 50x1-1/2" | 29 | 73 | 94 | 1-1/2" |
| 63x2" | 35 | 79 | 103 | 2" |
